OTW BeiDou GNSS Module B1I/B1C 25.6mm Ultra-Small Positioning

Place of Origin : China

Model Number : WT-11-AKB(Development Board)

Type : GNSS Module

Country of Origin : CHINA

Brand : OTW

Chipset : XX

Application : Positioning, surveying and mapping, etc

Operating mode : BDS

position accuracy : <1.5m

maximum height : 18000m

Voltage : 2.7V ~ 3.6V

Update frequency : 1Hz-10Hz(default 1Hz)

operating temperature : -40 to +85 degrees Celsius

Weight : 5.3g

Size : 25.6mm*26.5mm*11.8mm

MOQ : 1 piece

Price : $2.23-3.12 / piece

Contact Now

OTW BeiDou GNSS Module B1I/B1C 25.6mm Ultra-Small Positioning

Application：

● Personal positioning and track-tracking products for car navigation, location, etc. ●PDA, Pocket PC and other portable device field ●Surveying and mapping products such as area measurement and distance measurement. ●Synchronized UTC time and timing field ●Track recording and GNSS data point calibration. ●E-dogs, school cards and other products.

Features：

● Single Sided Surface Mount, Secondary SMT Solution, Faster Application ● Manufactured by lead-free process, RoHS compliant ● supports BeiDou II, BeiDou III, B1I and B1C ● supports A-GNSS and D-GNSS ●Support L1/B1/E1/R1 Frequency Points ●UART / TTL, USB2.0 optional outputs

Module performance
Model	WT-11-AKB (Development Board）
Receiver type	BDS B1I/B1C & B2a
Protocol	NMEA-0183 or Customized
Available Baud Rates	4800bps~921600bps
Number of Channels	32
Sensitivity	Tracking:-162dBm Capture:-160dBm Cold Start -148dBm
Cold Start	Average 29 seconds
Hot Start	2-3 seconds on average
Horizontal Accuracy	<2.5m
Maximum Height	18,000 meters.
Maximum speed	515 m/s
Maximum acceleration	≦ 4G
Update frequency	1-10Hz
Positioning method	A-GNSS

Port
Port	2 UART 2 SPI 1 I2C
Physical property
Type	18PIN stamp holes
Size	25.6mm26.5mm11.8mm (+/- 0.5mm)
Power supply
Voltage	3.6V~5.5V
Power Consume	Operation mode: 25mA@3.3V, Standby mode: 8mA (@3.3V)
Oerating Environment
Humidity range	5% to 95% non-condensing
Working Temperature	-40℃ to 85℃
Storage Temperature	-40℃ to 85℃

Company Profile

Shenzhen Anzewei Technology Co., Ltd. is a scientific and technological company integrating the R & D, production, sales and service of wireless positioning communication products, semi-finished products, finished products and supporting terminals. it has many international well-known enterprises in-depth cooperation resources and a number of elite and senior R & D and design teams.
We always take customer demand as the original strategy, providing wireless and portable high-end consumer electronics solutions, specializing in navigation, positioning, tracking, timing, communications, wireless connections and other professional products, semi-finished products and products, mainly centimeter-level positioning terminals, wearable children's smartwatches, pet track.

Logistics & Payment

FAQ

Q1: Are you a manufacturer? Where is your factory? A1: Yes, we are a manufacturer. Our factory is located in Shenzhen, China. Welcome to our factory. Q2: If i place an order how long will it take to delivery it？ A2: IT usually takes about only 7-10days on receipt of payment,depends on the quantity ordered and the stock status. Q3: Are the prices on the list final? A3: No, the price is negotiable. It depends on the quantity of your order. Q4: When can I get the price? A4: Usually we quote within 24 hours of receiving an inquiry. If you urgently need to get a price, please call us so that we can let me quote you as soon as possible. Q5: Can I ask for a sample before placing an order? A5: Yes, we are welcome to order samples to test and check the quality. Mixed samples are acceptable. Q6: Can it be customized? A6: Yes. We support custom requirements. Q7: How can you make our business build a long term good relationship? A7: 1. We maintain good quality and competitive price to ensure that our customers benefit; 2. We respect every customer as our friend and sincerely conduct business and make friends with you, wherever you come. If you would like to know more about our company, please contact us immediately.
